144000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
144000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
Description
ZR144KCE-TFD-950
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
144K = 144000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
144K = 144000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity146000
- Discharge ConnectionHorizontal
- Discharge ID7/8"
- Line Voltage (60Hz)480V
- Mounting ArrangementA
- Rated Voltage (60Hz)460
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionHorizontal
- Suction ID1-3/8"
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity144000 btu
- Discharge Line Height19.73
- Frequency50Hz, 60Hz
- Height21.0 in
- Length10.38 in
- Liquid Line Size7/8 in
- LRA125.0
- Max RLA20.7
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge5.3 pints
- Run CapacitorN/A
- Shell Height21 in
- Shipping Height32 in
- Shipping Length32 in
- Shipping Point37406
- Shipping Weight154 lb
- Shipping Width38 in
- Suction Line Height4.81
- Suction Line Size1 3/8 H 4.81 in
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight135 lb
- Width11.23 in
