160000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
160000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
Description
ZR160KCE-TED-965
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
160K = 160000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
E = External Module with CoreSenseTM Diagnostics/ Protection
D = 380/420-3-50 / 460-3-60
965 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
160K = 160000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
E = External Module with CoreSenseTM Diagnostics/ Protection
D = 380/420-3-50 / 460-3-60
965 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity154000
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity160000 btu
- Frequency50Hz, 60Hz
- Height22.21 in
- Length12.93 in
- Liquid Line Size1 1/4 in
- LRA150.0
- Max RLA25.7
- Motor Phase3
- Oil Capacity0 ml
- Shipping Height32 in
- Shipping Length32 in
- Shipping Weight179 lb
- Shipping Width38 in
- Suction Line Size1 3/4-12 in
- TechnologyScroll
- TypeHerm
- Voltage380/420/460
- Weight146 lb
- Width11.73 in
