18000 BTU R22-R407C 265-1 Phase Copeland Scroll Compressor
18000 BTU R22-R407C 265-1 Phase Copeland Scroll Compressor
Description
ZR18K5E-PFJ-830
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
18K = 18000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
P = 1 Phase
F = Internal Inherent Protection - One protector, use with contactor
J = 220/240-1-50 / 265-1-60
830 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
18K = 18000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
P = 1 Phase
F = Internal Inherent Protection - One protector, use with contactor
J = 220/240-1-50 / 265-1-60
830 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Line Voltage (60Hz)277V
- Rated Voltage (60Hz)265
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- Compressor Capacity18000 btu
- Frequency50Hz, 60Hz
- Motor Phase1
- Shipping Height13 in
- Shipping Length21 in
- Shipping Weight63 lb
- Shipping Width14 in
