190000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
190000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
Description
Emerson Electric Co. (Copeland) Scroll™ 1-3/8" ODF Soldered Suction, 7/8" ODF Soldered Discharge, 380 to 240 VAC 50 Hz 3-Phase, 460 VAC 60 Hz, 190000 BTU/Hr, R-22/R-407C/R-134A, Scroll Compressor with POE Oil and External Enhanced Protection for Air Conditioner
Specifications
- Used On Item: Air Conditioner
- Connection Size 1-3/8 Inch ODF Soldered (Suction), 7/8 Inch ODF Soldered (Discharge)
- Refrigerant Type R-22/R-407C/R-134A
- Nominal Capacity 190000 BTU/Hour
- Voltage Rating 380 to 240 Volt AC 50 Hertz, 460 Volt AC 60 Hertz 3-Phase
- Motor Type 3-Lead 3-Phase
- Cooling Efficiency 11.3 EER
- Includes POE Oil, External Enhanced Protection
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity181000
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity190000 btu
- Frequency50Hz, 60Hz
- Height22.21 in
- Length12.93 in
- Liquid Line Size7/8 in
- LRA173.0
- Max RLA31.4
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge3.17 pints
- Shipping Height18 in
- Shipping Length26 in
- Shipping Point37406
- Shipping Weight160 lb
- Shipping Width18 in
- Suction Line Size1 3/8 in
- TechnologyScroll
- TypeHerm
- Voltage380/420/460
- Weight146 lb
- Width11.73 in
