300000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
300000 BTU R22-R407C 460-3 Phase Copeland Scroll Compressor
Description
ZR300KC-TWD-965
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
300K = 300000 BTU
C = Model Series
T = 3 Phase
W = External Electronic Protection
D = 380/420-3-50 / 460-3-60
965 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
300K = 300000 BTU
C = Model Series
T = 3 Phase
W = External Electronic Protection
D = 380/420-3-50 / 460-3-60
965 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity296000
- Discharge ConnectionRotalock
- Discharge ID1-1/4"
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR22, R407C
- Suction ConnectionRotalock
- Suction ID2-1/4"
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity300000 btu
- Compressor EER11.7
- Frequency50Hz, 60Hz
- Height28.5 in
- Liquid Line Size1 3/8 in
- LRA250
- Max RLA42.9
- Motor Phase3
- Oil Recharge12.6875 pints
- RLA42.9
- Shipping Height36 in
- Shipping Length29.5 in
- Shipping Point37406
- Shipping Weight442 lb
- Shipping Width29 in
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight406 lb
