This product has been superseded by
45000 BTU R22-R407C 208/230-3 Phase Copeland Scroll Compressor
This product has been superseded by
45000 BTU R22-R407C 208/230-3 Phase Copeland Scroll Compressor
Description
ZR45KC-TF5-935
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
45K = 45000 BTU
C = Model Series
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
935 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
45K = 45000 BTU
C = Model Series
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
935 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- BrandCopeland
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR22, R407C
- Variety TypeScroll
- Compressor Capacity45000 btu
- Frequency50Hz, 60Hz
- Motor Phase3
- Shipping Height21 in
- Shipping Length15 in
- Shipping Weight67 lb
- Shipping Width14 in
