57000 BTU R22-R407C 208/230-1 Phase Copeland Scroll Compressor
57000 BTU R22-R407C 208/230-1 Phase Copeland Scroll Compressor
Description
ZR57K3E-PFV-950
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
57K = 57000 BTU
3 = Model Series
E = POE Oil - AK/DA or 3MA
P = 1 Phase
F = Internal Inherent Protection - One protector, use with contactor
V = 200-1-50 / 208/230-1-60
950 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
57K = 57000 BTU
3 = Model Series
E = POE Oil - AK/DA or 3MA
P = 1 Phase
F = Internal Inherent Protection - One protector, use with contactor
V = 200-1-50 / 208/230-1-60
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity55500
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size7/8"
- Variety TypeScroll
- Compressor Capacity57000 btu
- Frequency50Hz, 60Hz
- Height17.75 in
- Length9.69 in
- Liquid Line Size1/2 in
- LRA1
- Max RLA32.1
- Motor Phase1
- Oil Capacity0 ml
- Oil Recharge3.25 pints
- Shipping Height16 in
- Shipping Length30 in
- Shipping Weight75 lb
- Shipping Width16 in
- TechnologyScroll
- TypeHerm
- Voltage208/230
- Weight90 lb
- Width9.69 in
