68000 BTU R22-R407C 575-3 Phase Copeland Scroll Compressor
68000 BTU R22-R407C 575-3 Phase Copeland Scroll Compressor
Description
ZR68KCE-TFE-930
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
68K = 68000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
E = 500-3-50 / 575-3-60
930 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
68K = 68000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
E = 500-3-50 / 575-3-60
930 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity70000
- Line Voltage (60Hz)600V
- Rated Voltage (60Hz)575
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size7/8"
- Variety TypeScroll
- ApplicationAC/HP
- Compressor Capacity68000 btu
- Frequency50Hz, 60Hz
- Height17.75 in
- Length9.69 in
- Liquid Line Size1/2 Stub in
- LRA54.0
- Max RLA8.2
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge3.5 pints
- Run CapacitorN/A
- Shipping Height25 in
- Shipping Length33 in
- Shipping Point37406
- Shipping Weight170 lb
- Shipping Width22 in
- TechnologyScroll
- TypeHerm
- Voltage575
- Weight85 lb
- Width9.69 in
