94000 BTU R22-R407C 575-3 Phase Copeland Scroll Compressor
94000 BTU R22-R407C 575-3 Phase Copeland Scroll Compressor
Description
ZR94KCE-TFE-950
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
94K = 94000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
E = 500-3-50 / 575-3-60
950 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
94K = 94000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
E = 500-3-50 / 575-3-60
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity96500
- Discharge ConnectionStub
- Discharge ID7/8"
- Line Voltage (60Hz)600V
- Mounting ArrangementA
- Rated Voltage (60Hz)575
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionStub
- Suction ID1-1/8"
- Suction Line Size1-1/8"
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity94000 btu
- Frequency50Hz, 60Hz
- Height18.8 in
- Length10.38 in
- Liquid Line Size7/8 Stub in
- LRA80.0
- Max RLA12.0
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge5.3268 pints
- Run CapacitorN/A
- Shell Height18.8 in
- Shipping Height32 in
- Shipping Length32 in
- Shipping Point37406
- Shipping Weight144 lb
- Shipping Width38 in
- TechnologyScroll
- TypeHerm
- Voltage575
- Weight126 lb
- Width11.23 in
