125000 BTU R22-R407C 208/230-3 Phase Copeland Scroll Compressor
125000 BTU R22-R407C 208/230-3 Phase Copeland Scroll Compressor
Description
ZRD125KCE-TF5-965
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
D = Digital
125K = 125000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
965 = Bill of Material Product Variation
Z = Scroll Compressor
R = A/C Duty - R22, R134A, R407C
D = Digital
125K = 125000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
965 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
Specifications
- BrandCopeland
- Capacity122000
- HP10
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR22, R407C
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity125000 btu
- Frequency50Hz, 60Hz
- Height21.0 in
- Length11.55 in
- Liquid Line Size1 1/4 in
- LRA239.0
- Max RLA41.4
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge6.625 pints
- Shipping Height32 in
- Shipping Length32 in
- Shipping Point37406
- Shipping Weight167 lb
- Shipping Width38 in
- TechnologyScroll
- TypeHerm
- Voltage200/220/230
- Weight136 lb
- Width11.23 in
