72000 BTU R22-R407C 208/230-3 Phase Copeland Scroll Compressor
72000 BTU R22-R407C 208/230-3 Phase Copeland Scroll Compressor
Description
Emerson Electric Co. (Copeland) Copeland Scroll™ 72000 BTU, 200/220 VAC 50 Hz, 200/230 VAC 60 Hz 3-Phase, 4 to 6 HP, R-22/R-407C/R-134A, 10.8 EER, 3-Phase 3-Lead Single Voltage Motor, Internal Inherent Protection, Digital Modulation, Scroll Compressor with Polyol Ester Oil for High Temperature Air Conditioner
Copeland Scroll Digital compressor increases HVAC system efficiency via capacity modulation and provide energy savings by precisely matching compressor output to your heating or cooling needs. This technology is perfect for buildings or rooms which experience widely varying loads or where tight temperature and humidity control are needed.
Specifications
- Type: Fan Blade
- Used On: UDAP/UDAS 400 Unit Heater
Documents
Specifications
- BrandCopeland
- Capacity70500
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR22, R407C
- Suction Line Size7/8"
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity72000 btu
- Frequency60
- Height19.5 in
- Length9.7 in
- Liquid Line Size3/4 in
- LRA156
- Max RLA20.7
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge3.75 pints
- Shipping Height19.5 in
- Shipping Length9.7 in
- Shipping Point37406
- Shipping Weight88 lb
- Shipping Width9.7 in
- TechnologyScroll
- TypeHerm
- Voltage200/230
- Weight88 lb
- Width9.7 in
