Condensate Pump, 15' w/Safety Switch Auto Less Tubing 115V
Condensate Pump, 15' w/Safety Switch Auto Less Tubing 115V
Description
Franklin Electric Co., Inc. (Little Giant) (3) 1-1/8" Inlet, 3/8" Discharge, Barbed, 20' Head, 115 VAC 60 Hz, 1 A, 1/50 HP, 65 GPH, 6.5 PSI, ABS, Automatic, Vertical Centrifugal, Condensate Removal Pump
Features & Benefits
- Vertical Centrifugal Pump Design
- Automatic Start and Stop Operation
- Safety Overflow Switch Dual Function NO and NC Operation
- Built-In Wall Mount Tab on Tank
- Removable Pump Float Locking Tab for Safety During Transportation
Specifications
- Type: Automatic, Vertical Centrifugal
- Reservoir Inlet Size: (3) 1-1/8 Inch
- Discharge Size: 3/8 Inch
- End Connection: Barbed Outlet
- Overall Dimensions: 11 Inch Length x 5 Inch Width x 7.03 Inch Height
- Flow Rate: 65 GPH
- Discharge Head: 20 Foot
- Casing Material: ABS Plastic
- Shaft Material: Stainless Steel
- Reservoir Capacity: 1/2 Gallon
- Reservoir Material: ABS Plastic
- Housing Material: ABS Plastic
- Impeller Material: Glass Filled Polypropylene
- Power Cord Length: 6 Foot
- Power Rating: 1/50 HP
- Input Supply Rating: 115 Volt AC 60 Hertz 1 Amp
- Temperature Rating: 140 Deg F
- Pressure Rating: 6.5 PSI
- Motor Type: Thermally Protected, Fan Cooled
- Inclusions/Features: Safety Overflow Switch with (2) 5 Inch Lead Wire, 6 Foot 3-Conductor Cable, ABS Plastic Motor Cover/Tank Cover, Acetal Check Valve, (3) Prong Plug
- Application: Air Conditioning and Refrigeration System, Dehumidification Equipment, Oil and Gas-Fired Condensing Furnace, Condensing Boiler Equipment
- Applicable Standard: CSA (Canada and US)
Specifications
- BrandLittle Giant
- ApplicationGeneral Purpose
- Line Voltage (60Hz)120V
- Tubing Connection Size3/8"
