Features & Benefits

• Known for their Legendary Durability, Maneurop® Reciprocating Compressors from Danfoss Cover a Wide Range of Operating Conditions
• Maneurop MTZ Series Hermetic Reciprocating Compressors are Designed for High and Medium Temperature Applications
• These Compressors have a Large Internal Free Volume that Protects against the Risk of Liquid Hammering When Liquid Refrigerant Enters the Compressor

Specifications

• Size: 352 Millimeter Diameter x 538 Millimeter Height
• Color/Finish: Blue
• Used On Item: Refrigeration/Air Conditioner
• Applicable Standard: UL, CE
• Refrigerant Type R-134A/R-404A/R-407A/C/F/R507A (POE Oil)
• Capacity 160000 BTU/Hour
• Displacement Code 16.57 Cubic Inch per Revolution
• Motor Voltage Rating 380 to 400 Volt AC 50 Hertz 3-Phase/460 Volt AC 60 Hertz 3-Phase
• Current Rating 130 Amp (Locked Rotor)
• Motor Control Center 36 Amp
• Connection Type 1-3/4 Inch Rotolock x 1-1/4 Inch Rotolock
• Connection with Supplied Sleeve 1-1/8 Inch ODF x 3/4 Inch ODF
• Number of Cylinder 4
• Capacity Control Fixed Speed
• Gauge Port LP Schrader
• Glass Mounting Threaded
• IP Protection Class IP54 (with Cable Gland)
• Mounting Torque 50 Newton Meter
• Number of Starts 12 per Hour
• Oil Charge 3.9 Liter
• Oil Equalization 3/8 Inch Flare SAE
• Power Connection Screw Connector #10-32 UNF x 9.5 Inch
• Includes Oil Equalization Port and Sight Glass
