Specifications

• Item: Rotary Compressor
• Used On Item: Refrigerant, Air Conditioner
• Applicable Standard: UL (Canada and US)
Voltage Rating 200 Volt AC 50 Hertz/208 to 230 Volt AC 60 Hertz 1-Phase; Current Rating 26.3 Amp (Locked Rotor), 4.8 Amp at 60 Hertz (Rated Load), 7.7 Amp (Maximum Continuous Current); Power Rating 1 HP; Capacity 11700 BTU/Hour; Refrigerant Type R-22; Motor Resistance 2.52 Ohm (Main), 3.61 Ohm (Start); Connection Size 1/2 Inch ODF (Suction), 5/16 Inch ODF (Discharge); Oil Type Synthetic Alkylate; Motor Type PSC; Motor Starting Torque Normal; Compressor Cooling Fan; Temperature Rating 65 Deg F (Return), 95 Deg F (Ambient), -10 to 55 Deg F (Evaporating), 115 Deg F (Liquid), 45 Deg F (High and A/C); Application High Back Pressure
