2-1/8" Sweat (ODF) Liquid Line Filter Drier ,144 CU IN
2-1/8" Sweat (ODF) Liquid Line Filter Drier ,144 CU IN
Description
- Designed to accept any standard core
- Can be installed and leak tested without core
- Removable flange cover permits easy installation or replacement core
- Supplied with 1/4" pipe plug in flange cover
- Full flow fittings for low pressure drop
- Corrosion resistant epoxy powder paint finish
- Sturdy steel shells for long life durability
- 100 mesh outlet screen
- Solid copper fittings
Totaline Replaceable Core Shells offer the flexibility of using either replaceable Filter Cores as protection against solid contaminants, or replaceable Filter Drier Cores for protection against acid, moisture, and solids. They provide high liquid line flow capacities for larger air conditioning and refrigeration jobs.
NOTE: Cores not included, order separately.
Documents
There are no documents available.
Specifications
- BrandTotaline
- BurnoutNo
- Connection Material FinishCopper
- Connection TypeSweat (ODF)
- Core Material & FinishReplaceable Core
- Effective Volume Desiccant144
- Line TypeLiquid
- Nominal Connection Size2-1/8" in
- Length21.5625 in
- Maximum Working Pressure500 PSIG
- Shell Material & FinishPainted Steel
- Shipping Height11 in
- Shipping Length25 in
- Shipping Point37406
- Shipping Weight10 lb
- Shipping Width9 in
- TypeREPLACEABLE CORE
- UL ListedFalse
- UL ListedTrue
- UL RecognizedFalse
- UL RecognizedTrue
