Features & Benefits

• Designed for Easy Installation and Compatibility Dimensionally Identical to Original Carrier Chassis
• Full Range Heat Pump Operation with Reverse Cycle Defrost
• Exclusive Rust-Block Corrosion Protection
• High Efficiency PSC-Type Evaporator and Condenser Fan Motors with Built-In Temperature Protection
• Quiet, Durable and Efficient Compressor with Built-In Pressure and Temperature Protection
• Powder Painted Drain Pans
• High Efficiency Copper Tube-Aluminum Fin Evaporator and Condenser Coils
• DWDI Centrifugal Evaporator and Condenser Blowers
• Electronic Defrost Control
• Oversized Suction Accumulator
• Nichrome Electric Heaters with Built-In Limit Switches
• Slide-Out Electric Heater/Blower Module for Easy Room-Side Service
• Compressor Crankcase Heater
• High Pressure Switch with Lock-Out Circuit
• Refrigerant Circuit Access Ports
• Thermostatic Bi-Flow Expansion Valve
• Positive Shift Reversing Valve
• Precision Charged with zerOzone R-410A Refrigerant
• Made in USA

Specifications

• Voltage Rating: 208/230 Volt AC
• Current Rating: 1.5 Amp (Evaporator Motor), 1.4 Amp (Condenser Motor), 7.9 Amp (Rated Load), 42 Amp (Locked Rotor), 10.8 Amp (Total), 12.8 Amp (MCA), 27.1/30 Amp (Heater)
• Frequency Rating: 60 Hertz
• Number of Phases: 1
• Power Rating: 1/5 HP (Evaporator Motor), 1/4 HP (Condenser Motor), 5.6/6.9 Kilowatt
• Cooling Capacity: 17800 BTU/Hour
• Temperature Control Type: Thermostat
• Enclosure Material: Heavy Gauge G90 Steel
• Enclosure Finish: Galvanized
• Size: 28 Inch Width x 28-3/16 Inch Depth x 43-7/8 Inch Height
• Weight: 276 Pound
• Approval: UL
Heating Capacity 12500 BTU/Hour; Refrigerant Type R-410A; Compressor Type Reciprocating; Energy Efficiency Ratio 8 EER, 2.8 COP; Flow Rate 500 CFM; Filter Size 16 Inch x 20 Inch x 1 Inch
