7/8" Sweat (ODF) Liquid Line Filter Drier ,41 CU IN
7/8" Sweat (ODF) Liquid Line Filter Drier ,41 CU IN
Description
- Solid copper connections.
- High moisture and acid removal capacity.
- Corrosion resistant epoxy powder paint finish.
- Copeland products approved for POE oils
The ADK is a solid core liquid line filter drier good for use with CFC, HCFC, and HFC refrigerants.
Documents
There are no documents available.
Specifications
- BrandEmerson
- BurnoutNo
- Connection Material FinishCopper
- Connection TypeSweat (ODF)
- Core Material & FinishSolid Core
- Effective Volume Desiccant41
- Line TypeLiquid
- Nominal Connection Size7/8" in
- ApplicationLiquid Line
- Cutout Length8.56 in
- Diameter3.64 in
- Filter Drier Overall Length10.06 in
- Height3.64" in
- Lay In Length7.7 in
- Length10.06 in
- Maximum Working Pressure680 PSIG
- Shell Material & FinishPainted
- Shipping Height4 in
- Shipping Length12 in
- Shipping Weight5 lb
- Shipping Width4 in
- Solder Sprocket Depth0.75 in
- TypeSOLID CORE
- UL ListedTrue
- UL RecognizedTrue
- Weight3.78 lb
- Width7.7 in
