Specifications

• Type: Brazed
• Voltage Rating: 208/230 Volt AC
• Current Rating: 22.1 Amp Rated Load/137 Amp Locked Rotor (Compressor), 1.05 Amp Full Load (Condenser Fan Motor), 3.7 Amp Full Load (Pump Motor), 33.43 Amp (MCA), 50 Amp (MOP)
• Frequency Rating: 50/60 Hertz
• Number of Phases: 1
• Power Rating: 0.5 HP
• Cooling Capacity: 4 Ton
• Temperature Control Type: Microprocessor
• Connection Type: Terminal Block
• Cooling Coefficient: 3.19
• Operating Temperature: 55 to 120 Deg F
• Enclosure Material: Galvanized Steel
• Enclosure Finish: Baked Polyester Powder
• Size: 39.75 Inch Length x 16.25 Inch Width x 49.75 Inch Height
• Weight: 292 Pound
• Approval: ETL, ASHRAE 15, UL, NEC, ISO 9002
Refrigerant Type R-407C; Compressor Type Scroll; Energy Efficiency Ratio 10.88 EER; Heat Exchanger Type Brazed Plate; Speed Rating 1050 RPM (Condenser Fan Motor), 3450 RPM (Pump Motor); Temperature Rating 44 Deg F (Supply), 54 Deg F (Return), 150 Deg F (Storage); Maximum Pump Head Pressure Rating 50 Foot of Head; Water Connection Size 1 Inch (Supply), 1.25 Inch (Return); Expansion Tank Size 2 Gallon; Minimum Solution Content 25 Gallon; Airflow Rating 6.5 to 11.5 GPM; Internal Pressure Loss 1.68 Foot of Head; Refrigerant Capacity 88 Ounce; Application Global Residential and Light Commercial Micro Climate; Applicable Standard ASHRAE, NEC, ASME
