MOTOR
MOTOR
Description
ABB Motors and Mechanical Inc. (Baldor-Reliance) 3 HP, 200 VAC 60 Hz 3-Phase, 9.7 A, 1765 RPM, F Insulation, Steel 182T Frame, Foot Mount, F1 Mount Arrangement, Reversible, 4-Pole, 1-Speed, OPSB, General Purpose AC Motor
Features & Benefits
- ASTP (Advanced Scroll Temperature Protection) to Protect Compressor from High Discharge Temperatures
Specifications
- Item: Compressor
- Used On Item: High Temperature and Ultra High Pressure Air Conditioner Motor Type 3-Phase 3-Lead Single Voltage; Motor Protection External Enhanced; Nominal Capacity 182000 BTU; Refrigerant Type R-410A; Voltage Rating 380 Volt AC 60 Hertz 3-Phase; Power Rating 7 to 15 HP; Efficiency 11.2 EER; Includes Polyol Ester Oil
Specifications
- BrandBaldor
- Bearing TypeBall
- Enclosure TypeOPSB
- Frame Size182
- HP3
- Number of Speeds1
- RotationCCW/CW
- RPM1765
- Shaft Diameter1 1/8
- TypeBlower Motor
- Ambient40 °C
- CSA ListingTrue
- Frequency60
- Full Load Amps9.7
- Height8.95 in
- Length15 in
- Motor Phase3
- Mounting MethodRigid
- Service Factor1.15
- Shaft Length3.56
- Shipping Height8.95 in
- Shipping Length15 in
- Shipping Weight71 lb
- Shipping Width11.78 in
- TypeGeneral Purpose
- UL ListedFalse
- UL ListedTrue
- UL RecognizedFalse
- UL RecognizedTrue
- Voltage200
- Width11.78 in
