Features & Benefits

• Use Where Smooth Light Off is Important
• 1 Second Maximum Closing Time
• Continuously Displays the Valve Position with a Red Indicator When Open and a Yellow Indicator When Closed
• Mount in any Position Directly to Valve Bonnet with Three Setscrews
• Provide Final Safety Shut-Off Service When Used with V5055 or V5097 Gas Valves

Specifications

• Type: ON/OFF, Low Pressure, Standard
• Voltage Rating: 120 Volt AC
• Maximum AC Voltage: 120 Volt
• Current Rating: 0.94 Amp
• Frequency Rating: 60 Hertz
• Power Rating: 50 Watt
• Angle of Rotation: 52 Degree
• Enclosure: NEMA 1, IP30
• Size: 5 Inch Width x 6-3/4 Inch Depth
• Body Material: Die-Cast Aluminum
• Operating Temperature: -40 to 150 Deg F
• Application: Industrial Gas Valve, Gas Burner
• Approval: UL, CSA (Canada and US)
Maximum Safe Operating Pressure Rating 5 PSI; Timing 26 Second (Opening), Less than 1 Second (Closing); Excludes Auxiliary Switch
