1/2HP 208-230V 1075/1 CF 70C MOTOR
1/2HP 208-230V 1075/1 CF 70C MOTOR
Description
Totaline Condenser Fan Motor, Totally Enclosed, All Position Mounting
Documents
There are no documents available.
Specifications
- BrandTotaline
- Bearing TypeBall
- Enclosure TypeTEAO
- Frame Size48Y
- HP1/2
- Number of Speeds1
- RotationClockwise, Counter Clockwise
- RPM1075
- RPM Range1001-1100
- Shaft Diameter1/2
- Shaft PositionAll Angle
- TypeDirect Drive
- TypePSC Condenser Fan Motor
- Voltage208/230V
- Ambient70 °C
- CSA ListedTrue
- CSA ListingTrue
- Frequency60Hz
- Full Load Amps3.3
- Height5.6 in
- Length12.3 in
- Motor Phase1
- Motor RPM1075
- Mounting MethodBase, Stud, Strap
- Run Capacitor10/370
- Shaft Length6.0 in
- Shipping Height7 in
- Shipping Length15.5 in
- Shipping Point37406
- Shipping Weight10 lb
- Shipping Width7 in
- UL ListedTrue
- UL ListedTrue
- UL RecognizedTrue
- Voltage208/230
- Weight14 lb
- Width5.8 in
