15HP 208-230/460V 3PH 56FR CF MOTOR
15HP 208-230/460V 3PH 56FR CF MOTOR
Description
- Vertical shaft up mount
- Positioning screws in motor shell
- Water slinger for bearing protection
- Class B Insulation
- Reversible rotation
- NEMA 56 Frame
- 5/8 x 6" shaft with 5" flat and 5 long keyway
- key not provided
Totaline Condenser Fan Motor Three Phase
Documents
There are no documents available.
Specifications
- BrandTotaline
- Bearing TypeBall
- Enclosure TypeODP
- Frame Size56
- HP1-1/2
- Insulation ClassClass B
- Line Voltage (60Hz)480V
- Number of Speeds1
- RotationClockwise, Counter Clockwise
- RPM1140/1
- RPM Range1001-1100
- Shaft Diameter5/8
- Shaft PositionVertical Shaft Up
- TypeDirect Drive
- TypeCondenser Fan Motor
- Voltage208/230/460V
- Ambient60 °C
- CSA ListingTrue
- Frequency60
- Full Load Amps6.4/3.2
- Height6.5 in
- Length17 in
- Motor Phase3
- Motor RPM1140
- Mounting MethodBelly Band Mount
- Shaft Length6 in
- Shipping Height10.5 in
- Shipping Length19.5 in
- Shipping Point37406
- Shipping Weight33.85 lb
- Shipping Width10.9 in
- UL ListedTrue
- UL RecognizedTrue
- Voltage208/230/460
- Weight32.35 lb
- Width7 in
