Specifications

• BrandWeathermaker
• CFM1600
• Compressor Stage1
• ConfigurationVertical
• Cooling Capacity16500, 18000
• Gas Stages1-Stage
• Line Voltage (60Hz)240V
• Nominal Seer14
• RefrigerantR410A
• Suction Line Size3/4"
• Tonnage1.5
• Voltage (Phase)208/230 V 1-Phase
• Air FlowVertical
• CFM Nominal1600
• CompressorScroll
• Compressor RLA9
• Compressor TypeScroll
• Condenser Motor HP0.083
• Condenser Motor Phase1
• Condenser Motor RPM1100 rpm
• Condenser Motor TypePSC
• EER11.5, 13.5
• Fan Diameter18
• Frequency60
• Full Load0.4 amp
• Height24.8125 in
• High PressureFalse
• High Pressure SwitchFalse
• InverterFalse
• LEED CertifiedFalse
• Length23.125 in
• Liquid Line FittingSweat
• Liquid Line Size3/8
• Liquid Line Size0.375 in
• Locked Rotor47.5 amp
• Low PressureFalse
• Low Pressure SwitchFalse
• LRA47.5
• Maximum EER13.5
• Maximum Fuse Size20 amp
• Maximum Piping Length250 Ft.
• Maximum SEER16.5
• MCA12
• Metering DeviceTXV
• Minimum Ambient Temperature55° F °F
• Minimum EER11.5
• Minimum Heating Ambient Temperature55
• Motor Phase1
• Number Of Fan Blades2
• Outdoor Fan Motor FLA0.4
• Outdoor Number of Rows1
• Package Quantity1 ea
• Rated Load9 amp
• Rows1
• SEER14
• Shipping Height26.4375 in
• Shipping Length24.125 in
• Shipping Point37091, 38611, 66350, 78264
• Shipping Weight134 lb
• Shipping Width24.125 in
• Sound BlanketFalse
• Sound BlanketFalse
• Sound Level75 dBA
• Suction Line FittingSweat in
• Suction Line Size3/4
• UL ListedTrue
• UL RecognizedTrue
• Voltage208/230
• Warranty Offered10-Year Parts Limited Warranty With Timely Registration- Limited Warranty Period Is 5 Years If Not Registered Within 90 Days Of Installation
• Weight123 lb
• Width23.125 in
