Features & Benefits

• All Steel Case and Cover Built to Provide Long Lasting, Rugged Protection for Internal Component
• Sight-Set Calibrated Pressure Adjustment Displays a Visible Pressure Scale, Fully Adjustable Through the Range without Removing the Cover

Specifications

• Minimum AC Voltage: 120
• Maximum AC Voltage: 240
• Minimum DC Voltage: 120
• Maximum DC Voltage: 300
• Instrument Range: 12 Inch Hg to 100 PSI (Low Pressure Side), 100 to 500 PSI (High Pressure Side)
• Size: 5-11/16 Inch Width x 2-1/16 Inch Depth x 3-1/4 Inch Height
• Application: Dual Pressure Commercial Refrigeration and Air Conditioning
• Approval: UL
• Contact Configuration SPST
• Enclosure Type NEMA 1
• Pressure Rating 7 to 50 PSI Low Side, Manual Reset Lockout High Side (Differential)
• Current Rating 24 Amp at 120 Volt AC, 18.7 Amp at 208 Volt AC, 17 Amp at 240 Volt AC (Full Load), 144 Amp at 120 Volt AC, 112.2 Amp at 208 Volt AC, 102 Amp at 240 Volt AC (LRA)
• Motor Horsepower 2 HP at 120 Volt AC, 3 HP at 208/240 Volt AC, 125 Volt Amp at 120 to 600 Volt AC, 57.5 Volt Amp at 120 to 300 Volt DC (Pilot Duty)
• Pressure Connection 1/4 Inch External Flare Connector
