PRESSURE SWITCH
PRESSURE SWITCH
Description
Johnson Controls (Penn Controls) 1/4" Female Flare, 5.8/2.9 FLA, 4.8/15 RLA, 120 VAC, SPST, 410 PSIG, Snap-Acting Diaphragm, Non-Adjustable, Encapsulated, Direct Mount, Pressure Switch
Features & Benefits
- Compact Size and Lightweight Allow for Direct Mounting
- Trip-Free Manual Reset
- Contacts cannot be Overridden by Continued Depression of the Reset Button
- Dust Tight
Specifications
- Type: Non-Adjustable, Standard Duty, Encapsulated, Direct Mount
- Contact Configuration: SPST
- Contact Rating: 5.8 Amp at 120 Volt AC/2.9 Amp at 240 Volt AC (Full Load), 34.8 Amp at 120 Volt AC/15 Amp at 240 Volt AC (Locked Rotor), 375 Volt Amp (Pilot Duty)
- Application: Low Limit, High Limit and Fan Cycling Control in Commercial Refrigerant, Ice Machine, Food Service Equipment
- Approval: UL (Canada and US)
Specifications
- BrandJohnson Controls
- Burst Pressure3500 PSI
- Height4.8 in
- Length1.2 in
- Mounting MethodDIRECT
- Operating Humidity Range0 To 95
- Operating Temperature Range-20 To 150
- Power Rating375 VA
- Quick-Connect Terminal Description1/4 In Female SAE
- Shipping Height1.2 in
- Shipping Length5.2 in
- Shipping Point37406
- Shipping Weight0.3 lb
- Shipping Width4.3 in
- UL ListedFalse
- UL ListedFalse
- UL RecognizedFalse
- UL RecognizedTrue
- Voltage120/240
- Weight0.225 lb
- Width3.8 in
