Description
- Laser-welded stainless steel bellows
- Fixed or adjustable temperature settings
- High-amperage contacts
- Pneumatic action provided by vapor-filled capillary or capillary with bulb sensing elements
- Constant On or Off positions available
- Choice of mounting brackets, adjustment ranges and cams, and slotted or flatted shafts
- Standard 1/4 quick-connect terminals with optional screw terminals
A22/A30 Series Adaptable Constant Differential Control
- Switch: SPST
- Capillary Length: 84"
- Cold On: 23F
- Cold Off: 0.5F
- Differential: 22.5F
- Normal Off: 11F
- Normal On: 33.5F
- Warm On: 47F
- Off Position: Yes
Documents
There are no documents available.
Specifications
- BrandRanco
- Capillary Length84"
- Shipping Height2.7 in
- Shipping Length5.2 in
- Shipping Point37406
- Shipping Weight0.55 lb
- Shipping Width4.2 in
