Features & Benefits

• EPDM Material Provides Expanded Operating Temperature Range to -60F Degrees to 250F Degrees Which Helps Ensure Long-Life and Reliable Performance in the Most Demanding Climates and Heat Sensitive Applications
• Precision Molded Cogs-Provide More Surface Area for Heat Dissipation and Increase Belt Flexibility. Cooler Running Means Longer Life
• Browning Notched Belts Assure Longer Life when Replacing Existing Wrapped V Belts
• Close Belt Tolerance-Browning Belts Offer the "Code 1" Match Belt System on All Classical and "358" Belts, Allowing Easy Selection of Just One Match Number for Each Belt Size
• This Ensures Tighter than RMA Standards
• High Tensile Cord-Specially Treated Cords to Provide Strength and Additional Flex Life while Providing Resistance to Elongation for the Belt;.Raw-Edge Sidewalls-Improved Gripping Contract with Pulley Sidewalls
• Assures Less Vibration and Smoother, Quieter Performance
• Notched Belts Provide Higher Horsepower than Wrapped V-Belts

Specifications

• Type: AX, Notched
• Outside Circumference: 107.2 Inch
• Top Width: 1/2 Inch
• Thickness: 5/16 Inch
• Material: EPDM
• Application: Agitator, Brick Machinery, Blower and Exhauster, Bucket Elevator, Centrifugal Pump and Compressor, Exciter, Piston Compressor, Light Duty Conveyor, Belt Conveyor, Hammer Mill, Dough Mixer, Paper Mill Beater, Generator, Line Shaft, Laundry Machinery, Machine Tool, Punch Press Shear, Printing Machinery
• Applicable Standard: RMA
Height 0.3125 Inch; Band Type Belt with End Joined; Pitch Length 106.3 Inch; Efficiency 98 Percent; Operating Temperature Rating 250 Deg F; Reinforcing Cord Material Nylon; Number of Ribs 1
