31000 BTU R410A 460-3 Phase Copeland Scroll Compressor
![ZP31K5E-TFD-830_001.jpg](https://d1049ui2fjityy.cloudfront.net/userfiles/inriver/images/zp/31/k5/zp31k5e-tfd-830_001_medium.jpg)
![Copeland](/UserFiles/Brand/copeland_small.jpg)
31000 BTU R410A 460-3 Phase Copeland Scroll Compressor
Description
Emerson Electric Co. (Copeland) Scrollâ„¢ 5.5" x 15.3", 3/4" ODF Soldered Suction, 1/2" ODF Soldered Discharge, 380 to 240 VAC 50 Hz 3-Phase, 460 VAC 60 Hz, 31000 BTU/Hr, R-410A, Scroll Compressor with POE Oil and Internal Inherent Protection for Air Conditioner
Specifications
- Size: 5.5 Inch Diameter x 15.3 Inch Height
- Used On Item: High Temperature Air Conditioner
- Connection Size 3/4 Inch ODF Soldered (Suction), 1/2 Inch ODF Soldered (Discharge)
- Refrigerant Type R-410A
- Nominal Capacity 31000 BTU/Hour
- Voltage Rating 380 to 240 Volt 50 Hertz, 460 Volt AC 60 Hertz 3-Phase
- Motor Type 3-Lead 3-Phase
- Cooling Efficiency 10.2 EER
- Includes POE Oil, Internal Inherent Protection
Specifications
- BrandCopeland
- AvailabilityAvailable for Delivery
- Warehouse AvailabilityAVON, CRNE, MALD, WESE
- ApplicationA/C, HP
- Capacity31100
- Compressor Capacity31000 btu
- Discharge ConnectionHorizontal
- Discharge ID1/2"
- Discharge Line Height14.15
- Frequency50Hz, 60Hz
- Height15.3 in
- Length9.56 in
- Line Voltage (60Hz)480V
- Liquid Line Size1/2 in
- LRA38
- Max RLA6.4
- Motor Phase3
- Mounting ArrangementA
- Oil Capacity0 ml
- Oil Recharge1.3125 pints
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Run CapacitorN/A
- Shell Height15.3 in
- Shipping Height25 in
- Shipping Length16 in
- Shipping Point37406
- Shipping Weight53 lb
- Shipping Width20 in
- Start CapacitorN/A
- Suction ConnectionHorizontal
- Suction ID3/4"
- Suction Line Height10.3
- Suction Line Size3/4 in
- TechnologyScroll
- TypeHerm
- Variety TypeScroll
- Voltage460
- Weight48.4 lb
- Width9.56 in
Equipment Parts List
There is no data available for this product
