Features & Benefits

• Laser-Welded Stainless Steel Bellow
• Fixed or Adjustable Temperature Setting
• High Amperage Contact
• Pneumatic Action Provided by Vapor Filled Capillary or Capillary with Bulb Sensing Element

Specifications

• Type: 39 Inch x 3/8 Inch x 1-3/8 Inch Capillary, Cold Control
• Temperature Range: 38 Deg F (Cut-In), 9 Deg F (Cold Off), 15 Deg F (Normal Off), 22 Deg F (Warm Off)
• Contact Rating: 16 Amp at 120/240 Volt AC (Full Load), 80 Amp at 120/240 Volt AC (Locked Rotor)
• Connection Type: 1/4 Inch Quick-Connect
• Application: Kitchen, Utility Room, Laundry, Healthcare, Hospitality, Government, Education, Commercial Property Management and Refrigerator
• Approval: UL (Canada and US)
