Factory Authorized Part

THR 100 HW 100 SAE EE 5'VLF 6A

SKU:ALC-052912
Factory Authorized Part

THR 100 HW 100 SAE EE 5'VLF 6A

SKU:ALC-052912

    Description

    Emerson Electric Co. (White-Rodgers) 100 Ton Capacity, 450 PSIG, R-22, Maximum Operating Pressure, Pressure Limiting, Take-Apart, Bi-Directional, Adjustable Superheat, Large Capacity, Balanced Port, Refrigerant Thermostatic Expansion Valve with 5 ' Capillary Tube

    The T-Series Take-Apart valves, with adjustable superheat and replaceable, interchangeable components are ideal for original equipment and field replacements in air conditioning, heat pump and refrigeration applications.

    Features & Benefits

    • Take-Apart construction for easy field service
    • External superheat adjustment
    • Bi-directional capability
    • Stainless steel power assembly

    Specifications

    • Item: Thermostatic Expansion Valve
    • Used On Item: Refrigeration, Air Conditioner and Heat Pump
    • Equalizer Type External; Refrigerant Type R-12; Capacity 2 Ton; Capillary Length 5 Foot; Pressure Rating 450 PSIG; Bolt Torque Rating 300 Inch-Pound

    Specifications

    • BrandFactory Authorized Part
    • RefrigerantR22
    • Capillary Length60 in
    • Maximum Working Pressure450 PSIG
    • Shipping Height4.0945 in
    • Shipping Length6.772 in
    • Shipping Weight2.2 lb
    • Shipping Width4.173 in
