Features & Benefits

• Stroke 90 Degree Full Close
• Actuator Synchron
• The Damper Consists of a Galvanized Steel Frame and Heavy Duty Bottom Plate
• Damper Blade Shafts are Fully Enclosed in Celcon Bushings to Reduce Friction and Ensure Quiet Operation
• A High Density Foam Rubber Gasket with a Welded Galvanized Angle Affords an Efficient Seal to Minimize Blade to Frame Leakage
• The Motor and Shaft are internally Enclosed within the Damper Assembly
• The TREC Offers a Simple Slide in Installation and Motors are Easily Removed for Shaft and Pin Inspection

Specifications

• Item: Damper
• Type: Rectangular, Low Pressure, 1-Blade
• Overall Size: 10 Inch Width x 5 Inch Depth x 10 Inch Height
• Material: 20 Gauge Steel (Frame), 16 Gauge Steel (Front Plate)
• Finish: Galvanized
Supply Voltage Rating 24 Volt AC; Power Rating 12 Volt Amp; Motor Type Power Open, Spring Closed; Air Flow Rate 510 CFM; Air Velocity 1100 FPM; Differential Pressure Rating 0.5 Inch WC; Motor Mounting Type Side Mount; Temperature Rating -10 to 150 Deg F
