Features & Benefits

• Robust Design
• Flow Direction Arrow
• Quiet and Efficient Operation
• The Function of a Check Valve is to Allow Fluid Flow in One Direction Only
• Henry Technologies Check Valves are Suitable for HCFC and HFC Refrigerants, Along with their Associated Oils
• A Typical Application is to Install a Check Valve Downstream of an Oil Separator
• This Prevents Condensed Liquid Refrigerant Returning Down the Discharge Line and into the Separator

Specifications

• Type: Robust, In-Line
• Nominal Size: 3/8 Inch x 3/8 Inch
• End Connection: ODS x ODS
• End to End Distance: 153 Millimeter
• Body Material: Brass
• Spring Material: Stainless Steel
• Seat Material: Neoprene
• Temperature Rating: -29 to 100 Deg C
• Inclusions/Features: Copper Extension, Brass Piston
• Application: HCFC/HFC Refrigerant
• Applicable Standard: CE
