Features & Benefits

• Blower Start Relay Eliminates Field Installed Boiler Relay, Allowing Direct Wiring from the Boiler to the Air Handler
• Blower-On Fan Delay (Heating Mode) Preheats the HW Coil for 45 Seconds
• Blower-Off Fan Delay (Heating and Cooling Models) Blower Continues to Operate for 45 Seconds after Thermostat Is Satisfied, For Increased Efficiency
• 120 Volt or 24 Volt Zone Valve Control the Micro-Pro-Cessor Powers Either 120 Volt or 24 Volt Field Supplied Motorized Zone Valves
• Manual Air Vent on Hot Water Coil
• Blower Door Shut-Off Switch
• Slide Out Hot Water Coil for Easier Service
• Copper Tube Heating and Cooling Coils
• Attractive Baked-On Powder Coated Cabinet
• Primary and Secondary Condensate Drain Connections
• Easily Accessible 1 Inch Filter
• Cabinet Air Leakage is No More the 2 Percent When Tested in Accordance with ASHRAE 193
• The HBXB-HW Can be Directly Wired to a Boiler without Adding Additional Relays or Related Controls. Multiple Air Handlers Can be Connected to a Single Boiler to Provide Comfortable, Efficient, Whole House Hydronic Space Heating

Specifications

• Type: Upflow, High Efficiency, Split-System
• Voltage Rating: 120 Volt
• Current Rating: 8.5 Amp/10.63 Amp (Minimum Circuit Capacity)/15 Amp (Maximum Circuit Protection) (Motor)
• Cooling Capacity: 3 Ton
• Temperature Control Type: Multi-Function Microprocessor
• Connection Type: Screw-On
• Operating Temperature: 180 Deg F
• Installation: Horizontal
• Size: 20 Inch Width x 23 Inch Depth x 42 Inch Height
• Approval: ETL (Canada and US)
Coil Connection 3/8 Inch Liquid Line x 3/4 Inch Section Line; Motor Detail Power Rating 1/2 HP, Motor Speed 1340 CFM at 0.05 Inch External Static Pressure (High)/1290 CFM at 0.05 Inch External Static Pressure (Medium)/1200 CFM at 0.05 Inch External Static Pressure (Low); Filter Size 20 Inch x 22 Inch x 1 Inch; Water Temperature 63.3 BTU/Hour at 180 Deg F (High)/61.5 BTU/Hour at 180 Deg F (Medium)/59.4 BTU/Hour at 180 Deg F (Low); Potential Drop 7.5 Foot Water (High/Medium/Low); Without Pump; Includes Piston
