Features & Benefits

• Easy Reader Model is Easy to Read and Easy to Use
• Commercial Offers Occupied Damper or Economizer Control and Locking Cover and Subbase
• Staging Control for Nearly All Conventional and Heat Pump Systems
• 1-Stage Model Compatible with All Single Stage Systems Low Voltage, 750 Millivolt and 3-Wire Zone Systems
• Heat Pump Dual Fuel Option Eliminates the Need for a Fossil Fuel Kit
• Indoor Remote Sensor for Averaging Option
• Outdoor Remote Sensor Option on Select Universal Models for outdoor Temperature Reading and Dual Fuel Balance Point or Outdoor Thermostat Function
• Dual Power Hardwire and/or Battery or Tri-Power - Hardwire and/or Battery with System Assist

Specifications

• Type: Digital, Universal, 7/5-1-1 Day Programmable/Non-Programmable, 1-Heat/1-Cool 1-Stage, 2-Heat/2-Cool Multi-Stage, 4-Heat/2-Cool Heat Pump
• Cover Type: Horizontal
• Voltage Rating: 30 Volt AC (Battery Powered), 24 Volt AC 50/60 Hertz (Hardwired)
• Current Rating: 1.5 to 2.5 Amp (Load Terminal)
• Temperature Rating: 32 to 105 Deg F
• Size: 5.9 Inch Width x 1.2 Inch Depth x 4.6 Inch Height
• Display Size 12 Square Inch
• Terminal Designation RC, RH, C, W/E, W2, Y, Y2, O/B, G, 6, L, +, S, -, A1
• Set Point Temperature Rating 45 to 99 Deg F
• Humidity Rating 90 Percent (Non-Condensing)
• Inclusion/Feature Economizer Connection, Key Press or Continuous with Common Wire Backlight, Heat Pump Dual Fuel Control, Auto Changeover, Filter Change Reminder, Energy Mounting Recovery/Early Start, Setpoint Temperature Limit, Lighted Display, Cool Saving
• Application Gas/Oil/Electric, 3-Wire Zone Valve, Millivolt System
• Applicable Standard NEC Class II
