THERMAL EXPANSION VALVE
THERMAL EXPANSION VALVE
Description
Emerson Electric Co. (White-Rodgers) 35 Ton, Flange x Flange, 450 PSI, Stainless Steel, Bi-Directional, Externally Equalizer, Thermostatic Expansion Valve
Features & Benefits
- Suitable for Bi-Flow Applications
- External Superheat Adjustment
- Integral Body with Straight-Thru Connection
- Balanced Port Design Improve Valve Operation and Stability Over Wide Load and Evaporator Temperature Range
- Solid Copper Connection
- Large Diaphragm Provide Superior Stability
Specifications
- Type: Hermetic Balanced Port Design, Bi-Directional, Adjustable Superheat, Large Capacity, Straight Through
- Nominal Size: 1-1/8 Inch x 1-3/8 Inch
- End Connection: ODF Soldered x ODF Soldered
- End to End Distance: 4.6 Inch
- Pressure Rating: 450 PSIG
- Inclusions/Features: 1/4 Inch SAE External Equalizer, Large Diaphragm
- Application: Refrigerant, Air Conditioner, Heat Pump and Chiller
- Applicable Standard: UR/CUR Capillary Tube Length 10 Foot; Refrigerant Type R-22; Capacity 60 Ton; Charge Code Medium Temperature; Height 6.34 Inch
Replacement for
Specifications
- BrandFactory Authorized Part
- RefrigerantR22, R407C
- Capillary Length120 in
- Maximum Working Pressure450 PSIG
- Shipping Height4 in
- Shipping Length6 in
- Shipping Point37406
- Shipping Weight1 lb
- Shipping Width4 in
