UL CLASS CC TIME DELAY FUSE FO
UL CLASS CC TIME DELAY FUSE FO
Description
Littelfuse, Inc. POWR-GARD® 0.41" x 1.5", 600 VAC/300 VDC, 30 A, 200 kA AC Symmetrical, 20 kA DC, Ferrule Terminal, Class CC, UL Power Fuse
Features & Benefits
- Fuses is Time Delay Fuse Designed to Protect Control Transformer, Solenoid and Similar Inductive Components with High Magnetizing Currents During the First Half Cycle
- They Provide Excellent Protection of Motor Branch Circuits Containing IEC or NEMA Rated Motor Controllers or Contactors
- Extremely Current Limiting Reduces Damage Caused by Heating and Magnetic Effects of Short Circuit Current
- Rejection Feature Prevents Use of Fuses with Lower Interrupting Ratings or Voltage Ratings when Used with Corresponding Fuse Holder
- RoHS Compliant
Specifications
- Type: Class CC
- Characteristics: Time Delay
- Voltage Rating: 600 Volt AC/300 Volt DC
- Current Rating: 30 Amp
- Interrupting Rating: 200 Kiloamp (AC) Symmetrical, 20 Kiloamp (DC)
- Terminal Type: Ferrule
- Diameter: 0.41 Inch
- Length: 1.5 Inch
- Approval: UL, CSA, CE
- RoHS Compliant
- Material Melamine (Body), Nickel Plated Bronze (Cap)
- Application Transformer Protection
Documents
There are no documents available.
Specifications
- BrandLittelfuse
- Max Temp125
- Min Temp-55
- Amps30
- Length1.5 in
- MaterialMelamine
- Shipping Height3 in
- Shipping Length5 in
- Shipping Weight2 lb
- Shipping Width4 in
- TypeTime Delay
- UL ListedFalse
- UL ListedTrue
- UL RecognizedFalse
- UL RecognizedFalse
- Voltage600
- Weight0.019 lb
