Totaline 5L620 Smooth V-Belt
Totaline 5L620 Smooth V-Belt
Description
FRACTIONAL HP V BELT
TOTALINE V-Belts are built for maximum tension control, drive uniformity and long life, with minimum heat built-up and stretching on low horsepower electric motors and gasoline engines. They are designed for high speed operation, and drive center distances as 40° short as pulleys will allow.
TOTALINE V-Belts are built for maximum tension control, drive uniformity and long life, with minimum heat built-up and stretching on low horsepower electric motors and gasoline engines. They are designed for high speed operation, and drive center distances as 40° short as pulleys will allow.
Documents
There are no documents available.
Specifications
- BrandTotaline
- Belt TypeMultiple V-Belt
- Cross Section Height3/8"
- Cross Section Width21/32"
- Outside Length Range61-70"
- Size5L
- StyleSmooth
- Common Belt Size5L620
- MaterialRubber, Polyester Cord, Canvas Cover
- Outside Length62 in
- Shipping Height1 in
- Shipping Length3.3 in
- Shipping Weight0.567 lb
- Shipping Width3.3 in
- Size5L
- Thickness0.375
- TypeV Belt
- Weight0.567 lb
