Features & Benefits

• Take-Apart Construction for Easy Field Service
• External Superheat Adjustment
• Bi-Directional Capability
• Stainless Steel Power Assembly

Specifications

• Type: Take-Apart, Bi-Directional, Adjustable Superheat, Large Capacity, Balanced Port, Straight Through
• Nominal Size: 7/8 Inch x 1-1/8 Inch
• End Connection: ODF Soldered x ODM Soldered
• Pressure Rating: 450 PSIG
• Inclusions/Features: Stainless Steel Power Assembly
• Exclusions: Bleed Hole, Equalizer
• Application: Refrigerant, Air Conditioner and Heat Pump
Capillary Tube Length 10 Foot; Refrigerant Type R-22; Capacity 45 Ton; Charge Code Maximum Operating Pressure, Pressure Limiting; Bolt Torque Rating 300 Inch-Pound
