Features & Benefits

• Stainless Steel Replaceable Power Assembly Eliminate Corrosion and Prevent Valve Failure
• Two Body Size Provide Capacity from 1/4 to 20 Ton
• Bodies, Cages and Power Assemblies can be Ordered Separately or in Pre-Packaged Service Kits
• Bi-Directional Capability up to 3-1/2 Tons for R-22 on One Valve Superheat Control in Cooling and Heating

Specifications

• Type: Balanced Port Design, Bi-Directional, Adjustable Superheat, Standard Body, 90 Degree
• Nominal Size: 3/8 Inch x 1/2 Inch
• End Connection: SAE Flare x SAE Flare
• Pressure Rating: 450 PSIG
• Inclusions/Features: External Equalizer, Stainless Steel Power Assembly
• Exclusions: Bleed Hole
• Application: Refrigerant, Air Conditioner and Heat Pump
• Applicable Standard: UR/CUR, CRN
Capillary Tube Length 5 Foot; Refrigerant Type R-502; Capacity 2 Ton; Charge Code Medium Temperature
